120Vac Input AC LED Module FF Linear Series 50 / 60Hz Frequency

• • High total efficiency up to 110lm/W
  • Various CCT available:2700/3000/3500/4000/5000/5700/6500K
  • CRI:80/90/95 options
  • Macadam 3/5 steps color bin
  • Solutions for Down light/Ceiling light
  • AC line voltage 120V input directly
  • Power factor higher than 0.95
  • Low THDI:<18%
  • TRIAC dimmable







  General information

  P/N	Size	Input	Power	PF	Flux	Efficiency	CCT	CRI	Dimming
  	mm	Vac	W	-	LM	LM/W	K	-	-
  RL-HM280×30A2801H016-840TB	280×30	230	16	0.95	1760	110	4000	80	TRIAC
  RL-LM280×30A2201N016-930FB	280×30	120	16	0.95	1376	86	3000	90	TRIAC
  RL-LM280X40A2801N009-930FF	280x40	120	9	0.9	720	80	3000	90	TRIAC

  Note:1-Various CCT available(2700-6500K)；RL-XXXXXXXXXXXXXXX-840X(8-80CRI;40-4000K CCT)
  2-Typical Optical-electronic parameters above @ Ta=25℃
  Selection guide

  P/N	Size	Input	Power	PF	Flux	Efficiency	CCT	CRI	Dimming
  	mm	Vac	W	-	LM	LM/W	K	-	-
  RL-HM280×40A2801H016-827FF	280×40	230	16	0.9	1440	90	2700	80	TRIAC Flicker-free
  RL-HM280×40A2801H016-830FF					1520	95	3000
  RL-HM280×40A2801H016-835FF					1552	100	3500
  RL-HM280×40A2801H016-840FF					1600	110	4000
  RL-HM280×40A2801H016-850FF					1600	110	5000
  RL-HM280×40A2801H016-857FF					1600	100	5700
  RL-HM280×40A2801H016-927FF	280×40	230	16	0.9	1290	80	2700	90	TRIAC Flicker-free
  RL-HM280×40A2801H016-930FF					1360	86	3000
  RL-HM280×40A2801H016-935FF					1424	89	3500
  RL-HM280×40A2801H016-940FF					1600	100	4000
  RL-HM280×40A2801H016-950FF					1600	100	5000
  RL-HM280×40A2801H016-957FF					1520	95	5700
  P/N	Size	Input	Power	PF	Flux	Efficiency	CCT	CRI	Dimming
  	mm	Vac	W	-	LM	LM/W	K	-	-
  RL-LM280×40A1402H009-827FF	280×40	230	9	0.9	810	90	2700	80	TRIAC Flicker-free
  RL-LM280×40A1402H009-830FF					855	95	3000
  RL-LM280×40A1402H009-835FF					900	100	3500
  RL-LM280×40A1402H009-840FF					990	110	4000
  RL-LM280×40A1402H009-850FF					990	110	5000
  RL-LM280×40A1402H009-857FF					900	100	5700
  RL-LM280×40A1402H009-927FF	280×40	230	9	0.9	720	80	2700	90	TRIAC Flicker-free
  RL-LM280×40A1402H009-930FF					774	86	3000
  RL-LM280×40A1402H009-935FF					800	89	3500
  RL-LM280×40A1402H009-940FF					900	100	4000
  RL-LM280×40A1402H009-950FF					900	100	5000
  RL-HM280×40A2801H016-957FF					855	95	5700
